Raymarine HYPERVISIONT HV-300 Series - Cable Routing

4.2Cablerouting
Cableroutingrequirementsforthetransducercable
.
Important:
T
oavoidinterference,thecablemustberoutedasfarawayfromVHFradioantennadevices
andcablesaspossible.
•Checkthatthecableislongenoughtoreachthedisplayitwillbeconnectedto
.Optionalextension
cablesareavailable,ifrequired.
•Ensurethereisenoughslackinthetransducercable,atthetransducerend,toallowthetransducer
topivotupanddownduringadjustment.
•Ifyouintendtoroutethecablethroughthetransomthenyoushouldusethesuppliedescutcheon
platetocoverthehole..
•Securethecableatregularintervalsusingthesuppliedcableclips.
•Anyexcesscableshouldbecoiledupataconvenientlocation.
HV–300transducerextensioncable
Forbestperformance,cablerunsshouldbekepttoaminimum.However,forsomeinstallationsit
maybenecessarytoextendthetransducercable.
A4m(13.12ft)HyperVision™transducerextensioncable(A80562)isavailable
Itisrecommendedthatamaximumofonecableextensionsisused,withthetotalcablerunto
eachtransducernotexceeding6.3m(20.67ft).
Note:
TheHyper Vision™transducerextensioncablecanonlybeusedtoconnectaHVseriestransducer.
Connections39
