3.4Mounting
Deadriseangle
Thedeadriseangleistheangleofyourvessel’
shullmeasuredfromthecenterline.Thetransducer
canbeinstalledonvesselswithadeadriseangleof0°to25°.Thetransducershouldnotbeinstalled
onvesselswithadeadriseanglegreaterthan25°.
ItemDescription
1W aterline
2Centerline
3
DeadRiseAngle
4P arallelwithwaterline
Thedeadriseangleshouldbemeasuredontheoutsideofthehullusingananglefinderorsimilar
device .
Cuttingguide
Y oucanuseabespokecuttingguidetohelpyouguideyourfairingblockthroughthebandsaw.
Y oucancreatean‘L ’shapedcuttingguidebyjoiningtopiecesofwoodtogether.Thepiecesneed
tobethesamelengthorlongerthantheFairingblock.
Usetheholeslocatedinthecornersofthefairingblocktosecureittothecuttingguide.
Installation
27
