Raymarine HYPERVISIONT HV-300 Series User Manual

4.
1Generalcablingguidance
Cabletypesandlength
Itisimportanttousecablesoftheappropriatetypeandlength.
•UnlessotherwisestatedonlyusecablessuppliedbyRaymarine.
•Whereitisnecessarytousenon-Raymarinecables,ensurethattheyareofcorrectqualityand
gaugefortheirintendedpurpose.(e.g.:longerpowercablerunsmayrequirelargerwiregaugesto
minimizevoltagedropalongtherun).
Strainrelief
Useadequatestrainreliefforcablingtoensurethatconnectorsareprotectedfromstrainandwillnot
pulloutunderextremeseaconditions.
Cableshielding
Ensurethatcableshieldingisnotdamagedandthatallcablesareproperlyshielded.
Caution:Transducercable
•DoNOTusethetransducercabletoliftorsuspendthetransducer;always
supportthetransducerbodydirectlyduringinstallation.
•DoNOTcut,shorten,orsplicethetransducercable.
•DoNOTremovetheconnector.
Ifthecableiscut,itcannotberepaired.Cuttingthecablewillalsovoidthe
warranty.
38
