3.1Systemintegration
YourVHFradiocanbeconnectedtothefollowingmarineelectronicsdevices.
0
0
1 2
5 6
3
4
D12 611-1
0
0
ItemDevicetypeMaximumquantitySuitabledevicesConnections
1Ray260handset3Ray260handset1perbasestationhandsetconnection
2
ActiveSpeaker
3Ray260activespeaker1perhandset
3Passivespeaker3Ray260passivespeaker1perhandset
4Loudhailer1•30WattLoudhailer
•30WattLoudhailerwithlisten-back
power/datacable
5
Raymarinemultifunction
display
6
TheRay260iscompatiblewiththefollowing
Raymarinemultifunctiondisplays:
•aSeries
•cSeries
•eSeries
•gSSeries
•C-SeriesWidescreen(NMEA0183DSC
messagesonly)
•E-SeriesWidescreen(NMEA0183DSC
messagesonly)
•G-Seriessystem(NMEA0183DSC
messagesonly)
SeaTalk
ng
orNMEA0183
6
GPSReceiver
1
•RS130
•RS125
•Raymarinemultifunctiondisplayequipped
withinternalGPS
SeaTalk
ng
orNMEA0183withan
NMEA0183toNMEA2000converter.
Note:TheRay260doesnotsupportconnectiontoNMEA0183andSeaT alk
ng
atthesametime.
