CALL
OUT DESCRIPTION 106A 156A
B BURNER TRAY
1-B Burner Tray (Sea Level)*
Natural Gas 014841F 014842F
Propane Gas 014845F 014846F
Burner Tray w/Gas Valve (Sea Level)*
Natural Gas 014849F 014850F
Propane Gas 014853F 014854F
2-B Burner N/A N/A
3-B Burner Orifice (Sea Level)*
Natural 1.30mm 014857F/13 014858F/19
Propane .84mm 014861F/13 014862F/19
C CONTROLS
1-C Thermostat Auto Reset 135º Surface Mount 006725F 006725F
2-C P. C. Board/Control (Digital) N/A 013464F
3-C LCD Display N/A 013640F
4-C Fuse 5 AMP N/A 013733F
5-C Seal Gasket N/A 014866F
6-C Thermostat Control (Analog) 011585F N/A
7-C PC Board 014923F N/A
8-C Potentiometer 011586F N/A
9-C Temperature Sensor Analog (2 Wire) 011587F N/A
10-C Temperature Sensor Digital (3 Wire) N/A 009577F
G GAS VALVE
1-G Combination Valve Nat. 014867F 014867F
Combination Valve Pro. 014868F 014868F
H HEAT EXCHANGER
1-H Heat Exchange Assy Copper 014869F 014870F
2-H Inlet/Outlet Header Complete 014873F 014873F
Inlet/Outlet Header (Includes 6-H) 011595F 011595F
3-H Return Header (Includes 6-H) 011596F 011596F
4-H
5-H Baffle (Cupro Nickel) N/A N/A
6-H Flange Nut Kit 008259F 008259F
7-H O Ring Gasket (2) 011600F 011600F
8-H Sensor Adapter 006714F 006714F
9-H Bypass Kit 014880F 014880F
10-H Bypass Valve 006716F 006716F
11-H Bypass Dam / Shaft 006717F 006717F
12-H Bypass Spring 014881F 014881F
13-H Drain Plug 006721F 006721F
14-H Inlet/Outlet Header Dam 014882F 014882F
15-H Hose Adapter 1-1/2" MPT x 1-1/2" Hose (Optional) 011635 011635
16-H 2" CPVC Connector & Nut (2) 006723F 006723F
17-H O Ring Seal (2) 006724F 006724F
J CONTROL BOX
1-J Control Box Analog (Includes 7-C)
Natural Gas 014883F N/A
Propane Gas 014913F N/A
2-J Transformer 120/240/24V
Analog 011605F N/A
Digital N/A 006736F
3-J Ignition Control Natural Gas (Analog) 004817B N/A
Ignition Control Propane Gas (Analog) 004818B N/A
4-J Rocker Switch 009493F 009493F
*FOR ALTITUDES ABOVE 2,000 FEET ABOVE SEA LEVEL, CONSULT THE FACTORY.
