Raypak B-R259 - Page 45


NOTE: -BFHCC?LLBHJ<G;G;86BEE86GC4EG<G<F<@CBE
G4AGG;4GLBH FHCC?L G;8 ;84G8E @B78? AH@58EF8E<4?
AH@58E4A7GLC8B9:4FJ;8A4CC?<645?8
AL C4EG E8GHEA87 9BE E8C?468@8AG HA78E FG4A74E7
6B@C4AL J4EE4AG<8F @HFG 58 CEBC8E?L G4::87 J<G; 4
E8GHEA C4EGF G4: 6B@C?8G8?L 9<??87 <A J<G; G;8 ;84G8E
F8E<4?AH@58E@B78?AH@58E8G64A7F;<CC87GBG;8
B@C4AL9E8<:;GCE8C4<7
#9 78G8E@<A87 78986G<I8 5L G;8 B@C4AL 4A7 J<G;<A
J4EE4AGL 4 ?<>8 C4EG BE 8DH4? FH5FG<GHG<BA J<?? 58
E8GHEA879E8<:;G6B??86GE87<GJ<??ABG58<FFH87
MANUFACTURER:
,-'(/(.
)1(+
CALL
OUT DESCRIPTION 259 409
B BURNER
1-B Burner 014077F 014078F
2-B Gasket seal 014079F 014079F
3-B Burner Gasket Graphite (Includes 4-F) 014080F 014080F
4-B Gas Orifice Natural (0-2000 Ft)* 014082F 014081F
Gas Orifice Natural (2000-5000 Ft)* 014084F 014083F
Gas Orifice Propane (0-2000)* 014086F 014085F
Gas Orifice Propane (2000-5000)* 014088F 014087F
5-B Gas Orifice Flange O Ring 014089F 014089F
C CONTROLS
1-C Thermostat Auto Reset 135 Deg Surface Mount 006725F 006725F
2-C P. C. Board/Control 014090F 014090F
3-C LCD Display 013640F 013640F
4-C Fuse 5 AMP 013733F 013733F
5-C Temperature Sensor 009577F 009577F
6-C Flow Switch 007142F 007142F
7-C Flow Switch Paddle 010026F 010026F
8-C Switch Vent Pressure 007158F 007158F
9-C Switch Air Pressure Differential (Blower) 011760F 011760F
10-C Rocker Switch 009493F 009493F
F FAN
1-F Blower 014091F 014091F
2-F Blower Gasket 014092F 014092F
3-F Mounting Plate 014093F 014093F
4-F Mounting Plate Gasket (Includes 3-B) 014080F 014080F
5-F Combustion Air Orifice 014095F 014175F
6-F Combustion Air Venturi Adapter 014096F 014096F
7-F Intake Air Cap 012844F 012844F
G GAS VALVE
1-G Combination Valve - Nat. 014097F 014097F
Combination Valve - Pro. 014097F 014097F
2-G Bleedle Valve 1/8 NPT 007423F 007423F
H HEAT EXCHANGER
1-H Heat Transfer (Includes Refractory) 014098F 014099F
2-H Heat Exchange Assy.Cupro Nickel ASME BR 014100F 014101F
3-H Inlet/Outlet Header ASME BR Complete 014102F 014103F
Inlet/Outlet Header ASME BR 014104F 014105F
4-H Tube Bundle Cupro Nickel ASME ** 014106F 014107F
5-H Stud Bolt Kit (6) 014108F 014108F
6-H Header Gasket (2) 014109F 014109F
7-H Condensate Channel 014110F 014110F
8-H Condensate Plate 014111F 014111F
9-H Bypass Valve 006716F 006716F
10-H Bypass Spring 014112F 014113F
11-H Bypass Shaft 014114F 014114F
12-H Drain Valve 1/4 NPT 014158F 014158F
13-H Inlet CPVC Plug 014115F 014115F
14-H Outlet CPVC Plug 014116F 014116F
15-H O Ring 006724F 006724F
16-H 2" CPVC Nut 014160F 014160F
17-H 2" CPVC Connector & Nut 006723F 006723F
18-H 2" CPVC Nut 014160F 014160F
19-H O Ring 006724F 006724F
20-H 2" PVC Union Adapter 014161F 014161F
21-H Adapter with Buttress Threads 014162F 014162F
22-H 2" CPVC Connector & Nut 006723F 006723F
23-H O Ring 006724F 006724F
J CONTROL BOX
1-J Transformer 120/240/24V 006736F 006736F
2-J Blower Relay DPDT 24V 011720F 011720F
*FOR INSTALLATION AT OVER 2,000 FEET ABOVE SEA LEVEL, DERATE 4% PER I,000 FEET ABOVE SEA LEVEL.
**WARNING: The Hydraulic conditions or water chemistry that caused the tube bundle to fail have very likely also
damaged the bypass valve. We recommend to inspect the bypass assembly. Failure to do so could cause
premature failure of this replacement part.
