Raypak B-R259 - Page 46


CALL
OUT DESCRIPTION 259 409
M MISCELLANEOUS COMPONENTS
1-M PRV 125 PSI 011912F 011912F
2-M T & P Gauge 007399F 007399F
3-MWire/Harness 014117F014117F
4-M Blower Harness 120V 014118F 014118F
Blower Harness 240V 014119F 014119F
5-M Control Bezel (Includes Switch Decal) 014120F 014120F
6-M Switch/Decal-Membrane 014121F 014121F
7-M Tube Sheet Gasket 014122F 014122F
8-M Heat Exchanger Seal Gasket 014123F 014123F
9-M Window Combustion Chamber 006947F 006947F
10-M Blower / Air Pressure Switch Sample Tube 010348F 010348F
11-M Fastener Kit (Includes 6 each Bolt, Washer & Nutsert) 014174F 014174F
12-M Touch-up Paint Cool Dark Gray (Not Shown) 750256 750256
13-M RTV Sealant 2.8 oz (Not Shown) 008924F 008924F
RTV Sealant 10 oz (Not Shown) 005755F 005755F
PPILOT
1-P Igniter Direct Spark 014124F 014124F
2-P Igniter Gasket Upper & Lower 014125F 014125F
3-P Hi Tension Wire 014126F 014126F
R REFRACTORY
1-R Refractory Top & Bottom 014127F 014127F
2-R Refractory Top 014128F 014128F
3-R Refractory Bottom 014129F 014129F
4-R Refractory Support Top 014130F 014130F
5-R Refractory Support Bottom 014131F 014131F
S SHEET METAL / CABINET
1-S Jacket Top 014132F 014132F
2-S Flue Exhaust Gasket 014133F 014133F
3-S Front Control Bezel 014134F 014134F
4-S Control Bezel Cover 014135F 014135F
5-S Flue Collector 014136F 014136F
6-S Flue Collector Lower Gasket 014137F 014137F
7-S Flue Collector Upper Gasket 014138F 014138F
8-S Flue Exhaust Collar 009802F 009802F
9-S Flue Exhaust Gasket 009735F 009735F
10-S Flue Exhaust Cover Panel 009799F 009799F
11-S Flue Exhaust Gasket 009735F 009735F
12-S Chamber Assy 014139F 014140F
13-S Front Panels Left & Right 014141F 014141F
14-S Door Assy 014142F 014142F
15-S Door Insert SS 014143F 014143F
16-S Access Panel Intake Air 014144F 014144F
17-S Access Panel Igniter 014145F 014145F
18-S Jacket Side Panel Right 014146F 014146F
19-S Jacket Side Panel Left 014147F 014147F
20-S Jacket Rear Panel 014148F 014148F
21-S Flue Exhaust Cover 014149F 014149F
22-S Flue Exhaust Gasket 009738F 009738F
23-S Upper Cabinet Supports 014150F 014150F
24-S Vertical Cabinet Supports 014151F 014151F
25-S Window Reflector 014152F 014152F
26-S Control/Wiring Box Covers 014153F 014153F
V VENTING
1-V Stackless Top 014154F 014154F
2-V Flue Exhaust Gasket 014155F 014155F
3-V Flue Exhaust Gasket Retainer 014156F 014156F
4-V Retainer Stackless top Mtg 014157F 014157F
5-V Outdoor Stack Kit 013978 013978
6-V Flue Exhaust Gasket Retainer 010030F 010030F
7-V Outdoor Horizontal Vent Kit 014159 014159
8-V Flue Exhaust Outlet Adapter 6" x 7" 014050 014050
Flue Exhaust Outlet Adapter 6" x 8" 014051 014051
Flue Exhaust Outlet Adapter 6" x 9" 014052 014052
CONVERSION KITS* 259 409
Nat. to Pro. N/A N/A
Pro. to Nat. N/A N/A
* Gas conversions are to be done only by a qualified agency.
