R/F SENSOR: SPECIFICATIONS
Dimensions: 14 × 22 × 79 mm (0.5 × 0.9 × 3.1 in)
Weight: 42 g (1.5 oz)
Storage temperature: -25 – +70 °C (-13 – +158 °F)
Storage humidity: Non-condensing
Operating temperature: 15 – 35 °C (59 – 95 °F)
Operating atmospheric pressure: 70 – 110 kPa (3000 m above sea level)
Operating humidity: < 80 % relative humidity, non-condensing
Reference point: Center of upper sensor marking, depth indicated by line on the sensor
side
Direction of incident radiation: Orthogonal to the sensor marking surface
Minimum field of uniform
radiation:
The thick solid line marked on the sensor
Angular deviation, dose: < 1% within ± 10°
Backscatter: Insensitive to scattered radiation outside ± 70°
