Operation

52 Rev. G Nov/2015 MI3

<OUT1 Mode> defines the mode for the analog output:

<0-5V>

<0-10V>

<disable> output goes to high-resistance

<OUT1 Source> assigns the selected head to the analog output:

<#1>, <#2>, …, <Headmax>

<OUT1 Value> defines the basis for the output value:

<Tobject>: object temperature to be output

<Tambient>: head ambient temperature to be output

<OUT1 low temp.> defines the temperature for the low end of the analog output range (scaling)

<OUT1 high temp.> defines the temperature for the high end of the analog output range (scaling)

<OUT2 Mode> defines the mode for the analog output 2:

<0-20mA>

<4-20mA>

<0-5V>

<0-10V>

<disable> output goes to high-resistance

<OUT2 Source> assigns the selected head to the analog output:

<#1>, <#2>, …, <Headmax>

<OUT2 Value> defines the basis for the output value:

<Tobject>: object temperature to be output

<Tambient>: head ambient temperature to be output

<OUT2 low temp.> defines the temperature for the low end of the analog output range (scaling)

<OUT2 high temp.> defines the temperature for the high end of the analog output range (scaling)

<Interface> RS485/Profibus/Modbus:

<address>: unique address of the box in the network.

<baudrate>: baud rate for the box. Each device in the network must be set to the

same baud rate. The baud rate for Profibus is automatically negotiated between

master and slave.

Profinet/Ethernet:

<DHCP>: on/off – network protocol to configure a device in a network. DHCP

is switched off for Profinet communications.

<IP address>: a unique address of the box in the network, only changeable at

DHCP = off

<SubNetMask>: the subnet mask defines the interpretation of the IP address,

only changeable at DHCP = off

<Gateway>: a gateway connects two subnets at different subnet addresses, only

changeable at DHCP = off

<Port>: communication port, only changeable at DHCP = off, read-onlyfor

Profinet communications

<MAC>: MAC address, read-only

<Factory default> sets the box back to factory default.

The factory default values are to be found in section 18.8 Command Set,

page 121.

Spectral Response	8 to 14 µm
Response Time	500 ms
Display Resolution	0.1 °C
Accuracy	±1% or 1°C (2°F), whichever is greater
Emissivity	Adjustable 0.10 to 1.00
