Please note the correct mounting of the cable shield requires a strong metallic contact to the grommet.
Figure 50: Correct Mounting of the Cable Shield
The total sensing head cable length for all networked sensing heads must not exceed
30 m/98 ft (for MI3) and 2x30 m/2x98 ft (for MI3M)!
Correct position of the
shield before mounting
Shield with metallic
contact to the grommet
