REPAIR AND MAINTENANCE
Rear Wheel Hardware Sequence
15-1. Locknut
15-2. Spring Washer
15-3. Flat Washer
1 Loosen the 16 mm locknut and remove rear wheel(s).
2 Install replacement wheel(s) and tighten securely in place.
Note: the sequence of the hardware.
Rear Wheel Replacement
Required Tool: 16 mm Socket wrench
Rear Wheel Sleeve Replacement
1 Deflate tire and remove sleeve. 2 Slide replacement sleeve on to rear wheel. Align the
groove on the wheel with the inner lining of the sleeve.
Re-inflate tire to correct PSI (indicated on sidewall)
15-1
15-2
15-3
Groove
To Next Page
