Razor DXT User Manual

5
Need Help? Visit our web site for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer Service
contact information is listed at the back of this manual.
ASSEMBLY AND SET-UP
1 Place handlebars between the upper and lower
handlebar clamps.
Note: Make sure brake lever is on the left (from
sitting position).
2 Align the handlebars parallel to the front fork. Using
a 6 mm Allen wrench, tighten all four (4) bolts securely to
the upper crown.
Note: When properly tightened, the handlebars should
not move forward or backward.
Attaching the Handlebars
Required Tool: 6 mm Allen Wrench
Attaching the Seat
Required Tools: Two (2) 5 mm Allen Wrenches
1 Using two (2) 5 mm Allen wrenches, remove the four
(4) coupling bolts from the frame.
2 Place the seat at desired position. Align the four
(4) holes in the seat with the holes in the frame. Re-
insert the coupling bolts and tighten bolts until seat is
securely in place.
Attaching the Foot Pegs
Required Tool: 5 mm Wrench
L
R
1 Using an 5 mm Allen wrench, loosen the two (2)
coupling bolts on the foot pegs.
2 Slide the foot pegs onto the front of the
downtube, as shown, and tighten bolts securely.
Brake
Lever
Throttle

Razor DXT Specifications

General

Frame	Steel
Fork	Steel
Wheels	20-inch
Tires	20" x 2.125"
Brakes	Front and rear V-brakes
Gearing	Single-speed
Grips	Rubber
Saddle	Padded BMX style
Handlebar	Steel riser
