29
TTL33A loudspeakers can be stacked by themselves
on the FLY BAR TTL33A, or can be placed on top of
TT+ subwoofers (with the same FLY BAR TTL33A
fitted with the optional STCK BAR TTL33A rigging
frames) pinned to the grid.
Ground stacking configurations: on subs and directly on the ground
Secure sub enclosures with the optional STCK BAR TTL33A rigging
frames for subs using 2 quick lock pins for each bracket
Reverse FLY BAR TTL33A front bracket and use the optional STCK BAR
TTL33A rigging frames for subs for securing the frame to subs enclosures.
Connect the optional STCK BAR TTL33A rigging frames for subs and
the FLY BAR TTL33A front bracket using 2 quick lock pins for each
bracket.
The STCK BAR TTL33A link adds a fixed amount of up or downtilt to
ground-stacked TTL33A loudspeakers, with additional 19 degrees of
adjustment possible (from +11° to –8°).
