30
Use the optional STCK BAR TTL33A rigging frames for satellite
enclosures for securing them to the frame.
Depending on the two different holes on the FLY BAR TTL33A
frame various tilt angles of the whole array are possible. Check the
acoustical and mechanical set up with SHAPE DESIGNER software for
stacked set ups.
Connect front bracket of the first TTL33-A cabinet using 2 quick lock pins
The baffle of the bottom box in a stacked array does not necessarily have to be parallel to the stage or the array frame. It
can be tilted up or downward if desired. In this way arced arrays can be readily created from a ground stack position.
