12
TECHNICAL SPECIFICATIONS
PERFORMANCES
Max. cleaning capacity
(with 2 side brushes) m²/h 6875 6875
Cleaning width:
Main brush mm 700 700
Main brush + Right side brush mm 950 950
Main brush + 2 side brushes mm 1250 1250
Max. transfer speed km/h 6,5 6,5
Max. reverse speed km/h 4 3
Max. working speed km/h 5,5 5,5
Max. working gradient % 15 10
Max. gradient % 18 12
NOISE LEVEL (EN 60704)
Sound pressure level in operating position dB(A) 78 71
VIBRATION (ISO 2631/97)
Frequency weighted acceleration value m/s² < 0,5 < 0,5
BRUSHES
Main brush, length mm 700 700
Side brush, diameter mm 390 390
DUST VACUUM SYSTEM
Fan n°/type 1/centrifugal 1/centrifugal
Fan, diameter mm 230 230
Vacuum cut-off type mechanical mechanical
DUST FILTERING SYSTEM
Filtering system n°/type 5/cartridges 5/cartridges
Filtering surface m² 5 5
Filtering material type cellulose cellulose
Dust fi ltering shaker with automatic closing n°/type 1/electric 12V 1/electric 12V
ATOM SA
VERSION
Atom H SA Atom E SA
Petrol electric
