DCN 141-01128-04 10/6/08
11
Main Menu
The Thermostat has a menu tree that can be accessed by pressing the “Menu” button on the Main
Thermostat screen. Various configurations of the Thermostat can have different screen contents. The
first screen that will come up is the Main Menu screen. This is a list of the other menus or functions that
can be accessed. Standard screens are listed below. Yours may vary with different configuration or
revisions. Optional screens are selected in the Installer Settings screen during the system setup.
Schedules Screen: This screen is used to view and set the programmable setback schedules of the
thermostat.
User Settings Screen: This screen is used to set the Clock, Filter Service, Maintenance Service, Screen
Timeout, F/C mode, Sensor Calibration and Backlite/Display settings.
Thermostat Info Screen: This screen shows the firmware versions of the Thermostat and Zwave
interface, HVAC system type and equipment options.
Main Menu
Screen navigation buttons:
Menu Selection
Schedules
User Settings
Thermostat Info
Done
Return to Thermostat Screen
Not used
Not used
Select menu item at pointer
Select
Move menu selection pointer up
Move menu selection pointer down
To Next Page
