DCN 141-01128-04 10/6/08
25
Installer Settings Summary
Setting Range Default
Display Lock Y or N N Locks out front buttons
Service Mode Y or N N Turns on service mode shortens delays to
15 seconds. CAUTION no compressor
protection.
F/C Mode C or F F
Screen Timeout 0-240 0 seconds
Schedule Override Y or N N
Max heat setpoint 10 – 109 109
Min cool setpoint 6 – 110 6
Min Run Time (MRT) 1 – 9 6
Min Off Time (MOT) 5 – 9 6
Mechanical - Type Std or HP Std
Mechanical - Fan Type Gas or Elec Gas
Mechanical - C/O Type w/Heat or w/Cool w/Cool
Mechanical - 2
nd
Stage Heat Y or N N
Mechanical - Aux Heat Y or N N
Mechanical - 2
nd
Stage Cool Y or N N
Remote Sensor1 Type A-curve, Type 2,
Type 3
Type 2 Replaces internal sensor
Remote Sensor2 Type A-curve, Type 2,
Type 3
Type 2 Averages with primary sensor or an
outside sensor if location set to Out
Remote Sensor Location In or Out In
Filter Interval 300
Maint Interval 3000
H/C Delta 3 – 15 4
Heat Delta Stage 1 On 1 – 8 1
Heat Delta Stage 1 Off 0 – 8 0
Heat Delta Stage 2 On 1 – 8 4
Heat Delta Stage 2 Off 0 – 8 0
Heat Delta Stage 3 On 1 – 8 6
Heat Delta Stage 2 Off 0 – 8 3
Cool Delta Stage 1 On 1 – 8 1
Cool Delta Stage 1 Off 0 – 8 0
Cool Delta Stage 2 On 1 – 8 3
Cool Delta Stage 2 Off 0 – 8 0
Fan Cycler ON time 0 – 120 0 0 = Fan Cycler OFF
Fan Cycler Off Time 0 – 120 20
