DCN 141-01128-04 10/6/08
19
Main Menu - User Settings - Sensor Calibration
The Sensor Calibration screen allows you to change the temperature calibration for the internal and any
external remote temperature sensors attached to the Thermostat. You can change the temperature
calibration by +/- 7 degrees.
When the Sensor Calibration screen is selected it will show the internal and all detected remote sensors.
Each sensor found will show the current temperature (The (75) in the example screen below) and the
current number of degrees of offset being applied (1 deg in the example). “n/a” means that the remote
sensor is not attached. If the sensor’s actual temp is (74) with 0 degrees of offset and you want it to be
75, then press “+” to add 1 deg and it will show (75).
To change the temperature calibration, use the scroll buttons to select the internal or a remote sensor.
Once selected, use the + and – buttons to change the temperature calibration to the desired setting.
The value shown in the (xx) is the calibrated or offset temperature that you want the sensor to show.
You can refresh the info on this screen by pressing the right hand (blank) button.
When you close this screen, it may take a few seconds for the temperature displayed on the main
thermostat screen to update to the new temperature.
Sensor Calibration Screen
Screen navigation buttons:
Sensor Calibration
Internal (75) 1
Remote 1 n/a 0
Remote 2 n/a 0
Return to Main Menu Screen
Increase the temperature by 1 deg
Decrease the temperature by 1 deg
Refresh screen temperatures
Move menu selection pointer up
Move menu selection pointer down
