DCN 141-01128-04 10/6/08
13
Main Menu - Schedules - Heat and Cool Schedule Screen
When you select the Heat and Cool Schedule menu item, the “day” Schedule programming screen opens
and the schedule for current day will be displayed. Use the scroll buttons to highlight the data to be
modified. Once the data has been highlighted, use the +/- buttons to change the value of the data.
To copy a days schedule to another day or group of days, move the cursor to “c” on the bottom right of the
schedule screen. When you highlight the “c”, the button below will become “Copy”. Press this button to
change to the Copy Schedule Screen.
Schedule Screen
Screen navigation buttons:
Monday Schedule
Time Heat Cool
Morn 6:00 A 72 82
Day 9:00 A 68 84
Eve 5:00 P 74 76
Nite 10:00 P 70 78
+
_
c
Done
Next
Copy
Return to Main Menu Screen
Scroll Back
Scroll Forward
Select the next Day schedule
OR if the copy “c” is selected, go to
copy schedule screen.
To Next Page
