SPRAYMASTER 200
13
2.4 Flow-based Setup
2.4.1 Enable / Adjust Flow Sensor Cal Factor
Cal Mode 3 ( + Power-up ) - Channel 4: Default - All factors zero).
To enable flow-based regulation, at least one cal factor must be set > 0.
1. Press the '+' / '-' keys to select the appropriate sensor.
2. For the selected sensor (A to F), simply press and hold the key until
the factor appears, and adjust the value using the '+' and '-' keys.
The nominal cal factors are as follows,
Turbine Size pulse/litre pulses/Imp gallon pulses/US gallon
1/2" 3700 - -
3/4" 1786 8119 6760
1" 650.0 2955 2460
1-1/2" 165.0 749.1 624.5
2" 100.0 454.6 378.5
These values will suffice until you do a jug test (please refer to the Operation
Manual).
2.4.2 Select Default Flow Sensor
Cal Mode 1 ( + Power-up ) - Channel 5: Default - Channel disabled (All
factors set to zero).
If more than one sensor is enabled (i.e. the factor is >0), you can select
which to make current. The operator is then prompted to select/adjust the
flow sensor on normal startup.
For the selected sensor (A - F), simply press and hold the key until the
factor appears, and adjust the value using the '+' and '-' keys.
NOTE: You can also edit the cal factor for sensor A to F from here (as well as from
Cal 3, Channel.4).
