SPRAYMASTER 200
8
2. Calibration
2.1 Boom/Cutout Switch Setup
Boom configuration enables the instrument to automatically recognize the
correct number of nozzles in use at any moment in time.
2.1.1 Enable Single Boom Configuration (Standard)
Cal Mode 3 ( + Power-up ) - Channel 3: Setting = '[FuLL]', '1''
For the vast majority of sprayers, only a single boom configuration is needed,
in which case set the following,
(i) For single section sprayers fitted with a simple cutout switch, select "FuLL".
(ii) If connecting an ACI module into the sprayer switchbox, (it recognizes up to
9 boom sections), select "1". You can then proceed to programme the
number of nozzles and nozzle spacing for the individual sections.
2.1.2 Enable Multiple Boom Configuration
Cal Mode 3 ( + Power-up ) - Channel 3: Setting = '2', '3', 4', '5'
This is a special feature primarily for vineyard sprayers, enabling you to
programme up to 5 different boom configurations. The operator can then
simply select an appropriate boom configuration for a particular crop stage.
Select '2', '3', '4', or '5' . You can then proceed to programme the number of
nozzles and nozzle spacing for the individual boom sections, for each of the
boom configurations enabled.
NOTE: When 2 or more boom configurations are enabled, you will be prompted to
select the boom at startup.
2.1.3 Select Default Boom
Cal Mode 1 ( + Power-up ) - Channel 3: Default = Channel disabled
This channel only appears if 2 or more boom configurations are set (see
2.1.2 above), and allows you to set the default boom.
NOTE: You can also select the default boom during startup so you don't have
to use
this channel.
