SPRAYMASTER 200
4
The Spraymaster 200 can be retrofitted to almost any make or model of
sprayer - self-propelled, trailed or demountable, and configured for either
flow-based or pressure-based regulation. It is therefore, supplied as a
modular system comprising a Base Kit, plus individual kits specified as
required for the particular installation, e.g.
• Pressure sensor (mA output only)
and/or:
• Flow sensor (1/2", 3/4", 1", 1-1/4", 1-1/2" or 2" kit)
plus:
• Forward speed sensor (range of kits)
• Control valve (3/4", 1" or 2" kit)
• Cutout Switch (range of kits)
or:
• Serial ACI Interface (interfaces with sprayer switchbox)
1.1 Base Kit
The Base Kit comprise the following parts:-
P/SPRAY/BASIC
Item Part Number Description Qty
1 K/WIZ/MTG/BKT Head Unit mounting Bracket kit 1
2 K/INSTRUMENT/HC Power Supply Kit 1
3 K/7WAY/CONN/MK2 Demountable Kit 1
4 K/ACI/WIZARD ACI Interface 1
5 S/HU/327-17-001 Head Unit 1
6 S/HU/327-1-091 Terminator 1
7 S/DC/500-10-470 Terminator Label 1
# S/DC/500-10-464 Installation/Calibration Manual 1
# S/DC/500-10-467 Quick Reference Card 1
# S/DC/500-10-508 Installation Leaflet 1
# S/DC/500-10-463 Operation Manual 1
