SPRAYMASTER 200
14
2.4.3 Set No. of Sensed Nozzles
Cal Mode 3 ( + Power-up ) - Channel 5: Default =
This only needs to be set if an ACI and a flow sensor is installed.
Normally the sensed flow is for the full boom width, but in some installations
for practical reasons, it may only be the flow to a particular boom section.
Programme the total number of nozzles on the boom section(s) to which
liquid is delivered via the flow sensor.
You can set manually as follows. Press and hold the key, and adjust
the value using the '+' and '-' keys.
2.4.4 Valve Type
Cal Mode 3 ( + Power-up ) - Channel 6: Default =
If each boom section valve when closed, simply shuts off the flow (e.g.
solenoid valves), then set this channel to 'n' for a non-recirculating system.
If each boom section valve when closed, diverts the flow back to tank (e.g.
Arag or Spray Systems rotary ball valves), then set this channel to 'r' for a
recirculating system.
Press and hold the key, and adjust the value using the '+' and '-' keys.
2.5 Control Valve Settings
2.5.1 Response Factor
Cal Mode 2 ( + Power-up ) - Channel 2
The Response function sets the frequency at which the system adjusts the
control valve when reacting to a change in forward speed. A lower setting
results in a slower response, and increases the time taken for the application
rate to match the target rate. A higher setting results in a faster response. If
the application rate is unstable and varies about the target rate, then the
response setting may be too high.
Press and hold the key, and adjust the value using the '+' and '-' keys.
Default: Range: 0 - 9999
