RDS SPRAYMASTER 200 - Spraymaster 200 Installation Overview

SPRAYMASTER 200
3
1. Installation - Overview
Figure 1
Power
Supply Cable
S/CB/500
-
1
-
020
Pressure Control
Valve
To Sprayer
Control Valves
Speed Sensor
(alternative
installation)
Pressure Sensor
(4
-
20mA)
Flow Sensor
7-
way Connector
Kit
Forward Speed
Sensor
Sprayer
Switchbox
Serial Interface
(ACI)
S/AC/327-1-098
'Terminator'
Junction Box
S/AC/327
-
1
-
091
Head Unit
S/HU/327-17-001
BASE KIT
P/SPRAY/BASIC
