Record Power BS10 - Getting to Know the Bandsaw; Machine Components Overview; Specifications; Technical Specifications

8
Blade length: 1712 mm
Blade width: 6 - 10 mm
Max depth of cut: 100 mm
Throat depth: 245 mm
Table size: 340 x 335 mm
Max width blade to rip fence: 135 mm
Table height (from floor without leg stand): 379 mm
Table height (from floor with leg stand): 1057 mm
Extraction port: 40 mm
Motor power: 230 V / 50 Hz / 370 W
Weight: 35 kg
Size (without stand): H887 x W528 x D387 mm
Size (with stand): H1565 x W630 x D458 mm
Sound power level: <85 dBA
Sound pressure level: <85 dBA
5. Getting to Know the Bandsaw
6. Specifications
A Blade tensioning knob
B Rise & fall knob
C Blade
D Upper blade guides
E Mitre fence
F Rip fence
G Rip fence rail
H Table
I Optional leg stand
J Tracking knob
K Tracking knob lock
L Motor rating plate
M Table tilting handle
N 40 mm dust extraction port
O Motor
Item Description Item Description Item Description
A
B
D
E
G
H
I
K
J
L
M
N
O
C
F
