8. Machine Assembly
Components Included and Unpacking
The machine is supplied partly assembled. Prior to use, further assembly
is required.
When unpacking the machine the following components are included for
the initial assembly.
G
H
J
K
I
A BS10 Bandsaw
B Table
C Fence
D Fence rail
E Mitre fence
F Push stick
G M6 x 15 mm hex head screw
H Serrated washers x 4
I Wing bolts x 4
J Washers x 4
K 3 mm Hex key
L M6 x 30 mm hex bolt
M M6 nut
N 10 and 13 mm open ended wrench
O M6 nut and push stick holder
B
D
F
C
E
N
O
A
L & M
