Control lock
11
102-903109272 V1.0 13/ 13
Control lock
NOTICE
Undesirable manipulations on the control unit by unauthorised persons can be
hindered in a simple manner.
Control lock via ke
y
pad
Key sequence for locking:
Displayed symbol
Key sequence for unlocking:
Electronic control lock
To activate the electronic control lock, open up the connection between J2 /
1–2 (refer to the connection diagram).
Displayed symbol
11
