Record BDE-D User Manual

General information
1
102-903109272 V1.0 3/ 3
General information
Brief description
The BDE-D electronic control unit is a convenient input and output unit for the control and program-
ming of con-trol units in record door openers.
Logically arranged pushbuttons permit an intuitive op-eration of the door and navigation through the
drive-specific menu structure. The LCD display with back-ground lighting provides data and infor-
mation regarding the status of the door by means of symbols and plain text messages.
Several languages are available for selection, which in-creases the user friendliness on the one hand,
and fa-cilitates service interventions on the other.
The connection to the controllers takes place via the CAN bus in each case.
Document identification
Name: BAL_BDE-D_EN_1V0_REC_102-903109272
Article No.: 102-903109272
Version: V1.0
Technical Data
Supply voltage: 24 VDC from CAN bus
Connected load: < 2 W
Dimension of front panel: 60 x 60 mm, adapted for Feller or Jung systems
Dimension built-in type: 92 x 44 mm
Temperature range: -20… +50°C
Resolution of LCD display: 112 x 64 pixels, with background light
1
1.1
1.2
1.3

Record BDE-D Specifications

General

Brand	Record
Model	BDE-D
Category	Control Unit
Language	English
