Error elimination
13
102-903109272 V1.0 15/ 15
Error elimination
Symptom / Error
! Possible causes
→ Remed
y
No display after connection to the STG
! Wrong cable connector, incorrect pin configuration
→ Check connections to the CAN bus
Display after connection to the STG
! Only test routines are existing
→ Finish test routines, software update with FPC 902
Display is not easily readable
! Contrast may be to low or to high adjusted
→ Parameter / Control panel / BDE-D / adjust contrast
„?“ on display / in parameter value
! Unknown parameter in the STG or inexistent
→ Parameter programmieren oder STG updaten
