Identification
3
102-903109272 V1.0 5/ 5
Identification
1 Keypad with 6 keys 8 Navigation aid in the menu (scrollbar)
2 Navigation information 9 Menu lines (link to submenu)
3 LCD display 10 Slider control
4 Status displays (e.g. child-proof lock, re-
duced opening width)
11 DIP-switch CAN-termination / selector BDE
1 or 2
5 Operation mode (symbol and text) 12 Terminal board CAN bus
6 Title of main menu 13 Terminal board for external service lock
7 Cursor, active menu line
Front view Displa
y
Rear view
BUILT-IN TYPE
Front view
Rear view Side view
3
