3.4 Mechanical operating elements and displays
(1) Mechanical BDI (toggle switch) with three selectable
operating modes
(2) Reset button
(3) Status display
(4) Connection for service and configuration tools
(5) Mounting kit BDI-M
If a mechanical control unit BDE-M or an external control
is used, the toggle switch BDI must be replaced with the
option BDI-M.
