Redarc BCDC1225 User Manual

Loads
40A
Fuse
Battery
config
wire
Start
Battery
30A
Fuse
24V
Load
Fuse
All ground points must
be connected to chassis
earth.
Auxiliary
Battery
Note: Power wires must be
at least 6mm² and must be
crimped using an
appropriate crimp tool.
INPUT
SOLAR
Loads
40A
Fuse
Battery
config
wire
12 Solar Panel
Array
Load
Fuse
Note: Power wires must be
at least 6mm² and must be
crimped using an
appropriate crimp tool.
All ground points must
be connected to chassis
earth.
Auxiliary
Battery
INPUT
10
2 INSTALLATION
Figure 2.4 - Standard setup for a 24V Start Battery
Figure 2.3 - Standard setup for a 12V Solar array
