Owner’s Guide – Redback Smart Inverter - v1.4 21
Specifications
PRODUCT MODEL
SI5000
SI6000
SI8000
SI10000
PV PORT
Number of MPPTs
2
2
Strings per MPPT Input
1/1
2/1
MPPT Operating Voltage (range)
DC 70 - 540V DC 60 - 540V
Maximum Input Voltage (Vmax)
DC 550V
DC 550V
Maximum Current (Imp)
1
DC 15/15A
DC 30/20A
Short Circuit Current (Isc)
2
DC 20/20A DC 40/20A
Maximum Back Feed Current
0A
0A
Decisive Voltage Class (DVC)
DVC-C
DVC-C
Maximum PV Input Power
3
7500Wp 9000Wp 12000Wp 15000Wp
1
With firmware 120602 or newer
2
Manufacturer’s declared and tested Max Short Circuit Current (Isc Max)
3
Over-panelling benefits vary with
location.
GRID INTERACTIVE PORT
SI5000
SI6000
SI8000
SI10000
Nominal Output Voltage
AC 230V
AC 230V
Nominal Output Frequency
50Hz
50Hz
Rated Output Current
AC 21.7A
AC 26.1A
AC 34.8A
AC 43.5A
Max. Output Current
AC 25A
AC 27.3A
AC 40A
AC 45.5A
Rated Output Active Power
AC 5000W AC 6000W AC 8000W AC 10000W
Rated Output Apparent Power
5000VA
6000VA
8000VA
10000VA
Peak Output Apparent Power
5500VA
6000VA
8800VA
10000VA
Power Factor (range)
0.8 lagging to 0.8 leading 0.8 lagging to 0.8 leading
Output Voltage THD
<3%
<3%
Inrush Current
AC 52.92A/0.2ms
AC 95A/0.2ms
Maximum Output
Fault Current AC 79.38A/0.5ms AC 142.5A/0.5ms
Maximum Output Overcurrent Protection
AC 52.92A
AC 95A
Decisive Voltage Class (DVC)
DVC-C
DVC-C
EFFICIENCY
Maximum Efficiency
97.3%
97.5%
European Efficiency
96.5%
96.8%
PHYSICAL DATA
Installed weight
8.6kg
16.6kg
Shipping weight
10.7kg
20.6kg
Dimensions (W x D x H)
350 x 137 x 372mm
400 x 170 x 468mm
Dimensions Installed (W x D x H exc. cables)
350 x 147 x 407mm
400 x 192 x 531mm
Dimensions – Shipping carton (W x D x H)
445 x 428 x 240mm
600 x 480 x 300mm
Material
Aluminium
Aluminium
Finish
Sealed and powder coated
Sealed and powder coated
PV PORT ISOLATOR
Manufacturer Part Number
PEDS150-HM55R-4
NDG3V-50
Rated Insulation Voltage
1500V
1500V
Rated Impulse Withstand Voltage
8kV
8kV
Suitability for Isolation
C
C
Rated Operational Current (Ie)(Ue=1000V)
32A
40A
Utilization Category
DC-PV2
DC-PV2
Rated Short-time Withstand Current (Icw)
780A
760A
Rated Short-circuit Making Capacity (Icm)
1200A
1400A
Rated Breaking Capacity
4x Ie
4x Ie
