Introduction
8 O wner’s Guide – Redback ST10000 and BE14000-HV – v1.6
Know your product
Major components and dimensions
1. Wall mounting frame 13. Enclosure extractor fans (Filter cover)
2. Inverter module 14. Wi-Fi antenna
3. Balance of system module (BoS) 15. BoS switchgear hatch
4. Primary Battery Enclosure 16. Status panel
5. Secondary Battery enclosure (optional) 17. Inverter heatsink fins
6. Battery enclosure upper front cover 18. Blanking panels
7. Enclosure lower front cover 19. Battery System DC isolator (2, bridged)
8. Enclosure kick panel 20. PV Array DC isolator
9. Enclosure air inlet (Filter cover) 21. Backup circuit AC isolator (3, bridged)
10. Enclosure padlock hoop 22. Bypass switch (3, bridged)
11. Enclosure isolator 23. Inverter AC isolator (3, bridged)
12. BoS front cover 24. Thumbwheel
