Redback ST10000 - Specifications

Specifications
28 Owner’s Guide – Redback ST10000 and BE14000-HV – v1.6
Specifications
PV PORT
Number of MPPTs
2
Strings per MPPT Input
2/1
MPPT Operating Voltage (range)
DC200 – 550V
Maximum Input Voltage (Vmax)
DC600V
Maximum Current (Imp)
DC 12.5/22A
Short Circuit Current (Isc)
DC 15.2/27.6A
Maximum Feedback Current
0A
Decisive Voltage Class (DVC)
DVC-C
GRID INTERACTIVE PORT
Nominal Output Voltage
AC 400/380V
Nominal Output Frequency
50 Hz
Rated Output Current
AC14.5A/ phase
Max. Output Current
AC 16.5A / phase
Rated Output Active Power
AC 10000W
Rated Output Apparent Power
10000VA
Rated Input Current
AC 22.7 A/phase
Rated Input Apparent Power
15000VA
Power Factor (range)
0.8 lagging to 0.8 leading
Output Voltage THD
<3%
Inrush Current
45A, 2 µs
Maximum Output Fault Current
45A, 2 µs
Decisive Voltage Class (DVC)
DVC-C
BACKUP PORT
Nominal Output Voltage
AC400/380V
Nominal Output Frequency
50 Hz
Rated Current
AC 16.5A / phase
Rated Active Power
AC 10000W
Rated Apparent Power
10000VA
Peak Apparent Power
16500VA (60 sec max)
Power Factor (range)
0.8 lagging to 0.8 leading
Output Voltage THD
<3%
Inrush Current
45A, 2 µs
Maximum Output Fault Current
45A, 2 µs
Maximum Output Overcurrent Protection
45A, 2 µs
Decisive Voltage Class (DVC)
DVC-C
BATTERY PORT
Voltage (nominal)
DC 180 - 600V
Max. Current (charge)
DC 25 A
Max. Power (charge)
DC 10000W
Max. Current (discharge)
DC 25 A
Max. Power (charge)
DC 10000W
Battery Type
Li-ion
Battery Depth of Discharge
90%
Short Circuit Current
400A
Decisive Voltage Class (DVC)
DVC-C
