Owner’s Guide – Redback ST10000 and BE14000-HV - v 1.6 29
GENERAL INFORMATION
Operating Temperature
Unconditioned without solar effects
-35°C to 60°C
Operating Temperature Derated Output
below 10°C and over 45°C
Operating Relative Humidity
0 - 95%
Operating Altitude
0 - 4000m
Protective Class
I
Ingress Protection Rating
IP66
AC Overvoltage Category
OVC III
DC Overvoltage Category
OVC II
Active Anti-islanding Method
Active Frequency Drift
Moisture Location Category
4K4H
External Environment Pollution Degree
Grade 1, 2 and 3
Inverter Topology
Non-isolated
Country of Origin
China
Demand Response Modes
DRM 0
Standby Self-Consumption
<15W
Noise Emissions
<30 dBm
Warranty
10 years
EFFICIENCY
Maximum Efficiency
97.60%
Maximum Battery to Load Efficiency
97.50%
European Efficiency
96.80%
PHYSICAL DATA
Installed weight
Including 4 batteries
172-302kg
Including 8 batteries
210-378kg
Dimensions (W x D x H mm)
ST10000 + 1x BE14000-HV
566 x 360 x 1960
ST10000 + 2x BE14000-HV
1175(min) x 360 x 1960
Material
Aluminium cabinet and front covers; Stainless steel fittings
Finish
Powdercoat and internal sealant
BATTERY ENCLOSURE DATA
Enclosure Model
BE14000-HV
Name
Smart Hybrid Battery Enclosure
Number of Battery Units (N)
4 or 8
Storage Capacity
N x 2.4kWh
N x 3.55kWh
Battery System Model
RB-HVS-Nx48-50
RB-HVS-Nx48-74
Maximum Capacity
28.4kWh
Nominal Voltage
DC N X 48V
Rated Current
DC 25A
Fan Specification
DC 12V / 0.3A x2
Protective Class
I
Ingress Protection Rating
IP54
Dimensions (W x D x H mm)
545 x 348 x 1125
Material
Steel cabinet; Aluminium front covers; Stainless steel fittings
Finish
Powdercoat and internal sealants
