Specifications
30 Owner’s Guide – Redback ST10000 and BE14000-HV – v1.6
ISOLATORS
PV
PORT
GRID
INTERACTIVE
PORT
BACKUP
PORT
BATTERY
PORT
BATTERY
CABINET
Manufacturer Part Number
XBE+3610
S203-C40
S203-C25
S802PV-SP32
NoArk Ex9BP
Rated Insulation Voltage
1100V
440V
440V
DC1500V
DC1000V
Rated Impulse Withstand Voltage
8kV
4kV
4kV
8kV
4kV
Suitability for Isolation
C
C
C
C
C
Rated Operational Current
16A
40A
25A
32A
32A
Utilisation Category
DC-PV2
A
A
A
A
Rated Short-time Withstand Current (Icw)
700A
-
-
-
-
Rated Short-ciruit Making Capacity (Icm)
1000A
-
-
-
-
Rated Breaking Capacity (Isc)
5kA
15kA
15kA
5kA
10kA
COMMUNICATIONS PORTS AND PROTOCOLS
Ethernet
RJ45; Straight-thru
DRED
RJ45; DRED
Relays
RJ45; 3x Ditial I/O; +DC5V & GND
kWh Meter
RJ45; RS485 MODBUS
RS485
RJ45; Factory Use Only
Wi-Fi
802.11b/g/n/ac; 2.4GHz
LTE
na
Interlock
na
USER INTERFACE
Front Panel Display
Coded, coloured LEDs
Communications
Bluetooth for commissioning; Wi-Fi or ethernet for remote access
Remote Access
Web Portal; MYRedback app
Power/Energy Monitoring
Includes 1 x utility grade energy meter (class 1)
CERTIFICATIONS AND APPROVALS
AS/NZS 4777.2:2020
IEC 62109
-1:2010
IEC62109
-2:2011
IEC 62116:2014
IEC 62040-1:2017
IEC 62477-1:2012
IEC 60529
EN 61000
RCM
CE Mark (LVD, EMC, RoHS directives)
DESIGNED WITH INSTALLATION STANDARDS CONSIDERED
AS/NZS 3000:2018
AS/NZS 5139:2019
AS/NZS 5033:2014 (inc. Amd 1 & 2)
