7
1.0 TECHNICAL DATA
Model
1275 1575 / 1575LV 2075
Working width 1.20 m (47.2”) 1.58 m (62.2”)
2.08 m (81.9”)
Working depth 5 mm - 20 mm (0.19” - 0.78”)
Seeding speed
Up to 12 km/h (7.5 mph)
Weight 665kg (1315 lbs) 1160kg (2293 lbs) /
825 kg (1819 lbs)
1480 kg (3042 lbs)
Seeding row distance 75 mm (2.9”)
Number of cutting
elements
16 21 28
Recommended tractor 30 HP with minimum
lifting capacity of
800 kg (1764 lbs)
40 HP with minimum
lifting capacity of
1300 kg (2866 lbs)
35 HP – 950kg (2094
lbs)
50 HP with minimum
lifting capacity of
1600 kg (3527 lbs)
Seed-tray capacity 168 ltr. (5.9 cu. ft) 225 litres (7.9 cu. ft.) 300 litres (10.6 cu. ft.)
Maximum capacity
(theoretically at maximum speed
12 km/h (7.5 mph) and single
passage)
13950 m
2
(150156
ft
2
)
18900 m
2
(203438
ft
2
)
24900 m
2
(268021
ft
2
)
Seeding density per
100 m
2
(1076.4 ft
2
)
Fine seed: 0.2 - 2.8 kg (0.44 - 6.17 lbs)
(adjustable in 10 steps)
Coarse seed: 0.2 - 4 kg (0.44 – 8.82 lbs.)
(adjustable in 10 steps)
Shipping dimensions L x W x H
1000 x 1480 x
1450 mm
58.3” x 39.4” x 57.1”
L x W x H
1000 x 1874 x
1450 mm
39.4” x 73.8” x 57.1”
L x W x H
1000 x 2374 x
1450 mm
39.4” x 93.5” x 57.1”
Three-point connection Three-point CAT 1-2
Lubricant EP 2
Tyre pressure 1 – 2 bar (14.5 - 29 psi)
Standard parts Fillable back roller with scraper.
5 gear sets for adjusting the seeding density.
Integrated seed spreading tray.
Manual container.
Seed tray with sight-glass.
Seeding wheel adjusting to the area.
Independent cutting elements adjusting to the area.
Adjustment legs for storage.
