12. OPTIONS: WEIGHT KIT
The Multi-Seeder has a front beam to which the weights (1) can be attached. (Figure 12)
Figure 12
To mount the weights is to me as follows:
1. Remove the locking pin (2).
2. Mount the desired number of weights (1) onto the shaft.
3. Place the lock pin (2) onto the frame
Per machine, the following weights are available:
- Multi-Seeder 1200: 6x 492.502.800 (120Kg) (265 lbs)
- Multi-Seeder 1600: 14x 492.502.800 (280Kg) (617 lbs)
- Multi-Seeder 2100: 22x 492.502.800 (400Kg) (880 lbs)
OTHER COMMENTS:
ALWAYS FIX THE WEIGHTS ON THE MACHINE WITH THE SUPPLIED LOCKING
PINS. IF THIS ISN’T DONE CORRECTLY THE WEIGHTS COULD FALL OFF THE
MACHINE WHILE MOVING AND INJURE PEOPLE OR DAMAGE PARTS.
!! NEVER CRAWL UNDER THE MACHINE !!
!! SWITCH OFF THE TRACTOR BEFORE GETTING OFF !!
