6. Carefully remove the left throttle handle half.
7. Remove the safety catch (G) and the spring (H).
8. Make a note of the position of the throttle cable.
9. Remove the throttle cable from the throttle trigger.
10. Make a note of the position of the recoil spring.
11. Remove the throttle trigger, throttle trigger lockout,
and the recoil spring.
12. Make a note of the position of the cables.
13. Remove the cables from the start switch.
14. Assemble in the opposite sequence.
1351 - 002 - 25.11.2020 Repair instructions - 29
