6. Put an assembly sleeve on the crankshaft on the
clutch side to prevent damage to the sealing ring.
Lubricate the crankshaft with oil and install the
sealing ring.
7. Assemble the remaining parts in the opposite
sequence of
To get access to the crankcase and
crankshaft on page 38
.
7.15 Fuel tank
7.15.1 To do a tank venting
1. Drain the fuel tank.
2. Turn the product with the top down.
3. Remove the air filter cover. Refer to
To remove and
install the air filter on page 17
.
4. Remove the transparent fuel hose (A) from the
carburetor and connect it to the pressure tester.
5. Tighten the fuel tank cap. Make sure that the are no
leaks around the bushings in the fuel tank.
6. Use the pressure tester to make a negative pressure
in the tank. If there is no pressure or the negative
pressure is very low, replace the fuel tank.
7.15.2 To remove and install the fuel tank
1. Drain the fuel tank.
2. Remove the throttle handle. Refer to
To remove and
install the throttle handle on page 27
.
3. Remove the 2 screws to loosen the fuel tank from
the engine body.
44 - Repair instructions 1351 - 002 - 25.11.2020
