CLAMPING
13
7
01-2376 Screw
8
—
Mat (see chart, this
page)
9 01-2395
Screw
10
20-0214
Cover Plate
20-0214-0-275
Cover Plate, right
CW-AGF
20-0214-0-175
Cover Plate, left
CW-AGF
11 20-0093-0-004
Trimmer Hook
12
01-2075
Screw
13
20-0092-04X34
Trimmer Actuator
14
20-0655-0-039
Cover Plate
15
01-2084
Screw
16
—
Throat Plate (see
chart this page)
17 20-0281
Bearing Stud
18 01-6103
Pivot Pin
19
01-2018
Set Screw
20
01-2355
Screw
21
01-6055
Pin
22
20-0190-1
Clamp Tailpiece
23
20-0332-2
Unclamping Handle
24
20-0606
Spring Guide
25
01-5082
Spring
26
01-2111
Screw
27
20-0698
Gauge
28
20-0590
Gauge
29
20-0591
Gauge
30
01-2317
Screw
31
20-0722-0-063
Thread Holder, left
32
20-0722-0-064
Thread Holder, right
CLAMP FEET
PART NUMBER
DESCRIPTION
SIZE
TYPE
CORRUGATION
2a0196-1-337
Short
Right
20-0196-1-336
Short
Left
20-0196-1-331
Long
Right
FINE
20-0196-1-330
Long
Left
20-0196-1-352
1/2"
2 used
204)196-a066 Short
Right
FINE
20-0196-0-065
Short
Left
For Thread Holders
20-0196-0-068 Long
Right
see details 31 & 32
20-0196-0-067
Long
Left
Page 10
20-0196-1-237
Short
Right
20-0196-1-236
Short
Left
COARSE
20-0196-1-231
Long
Right
2a0196-1-230
Long
Left
20-0196-0-135
20-0196-0-129
Short
Long
2 used
2 used
RUBBER SOLED
THROAT PLATE AND MA"^
Throat Plates and Mats are available in the following bites and csrrugations. When replacing these
THROAT PLATE
MATS
PART NUMBER
BITE
PART NUMBER
CORRUGATION
2a0051-0-023
Narrow 1/16"
20-0208-1-323
FINE
20-0208-1-423
SMOOTH
2a0051-0-022
Medium 5/64"
20-0208-1-322
FINE
20-0051-0-024
Regular 3/32"
20-0208-1-324
FINE
20-0208-1-224
COARSE
20-0208-1-424
SMOOTH
20-0051-0-025^
Wide 3/32"
20-0108-1-324
FINE
20-0108-1-224
COARSE
20-0108-1-424
SMOOTH
*Differs from 20-0051-0-024 only in the location of the cutting slot.
