5.3 All-Terrain Scaffold Specifications
Table 5-2 All-Terrain Scaffold Specications
SPECIFICATION BRONCO
Unit Size (L x W x H)
Note: width is at the widest point.
37.7 in. x 28.5 in. x 33.7 in.
(958 mm x 724 mm x 856 mm)
Fully Extended Unit Size (L x W x H)
Note: width is at the widest point.
44 in. x 28.5 in. x 55.3 in.
(1118 mm x 724 mm x 1405 mm)
Platform Capacity 600 lbs (272 kg)
All-Terrain Scaffold Weight 16 lbs (7.26 kg)
Max Working Height* 11 ft (3.3 m)
A
Maximum Platform Width 24 in. (610 mm)
B
Maximum Suggested Platform Length*** 32 ft (9.75 m)
C
Minimum Platform Height** 36 in. (914 mm)
D
Maximum Platform Height** 59 in. (1499 mm)
*Based on 4 in. platform height plus 6 ft.
**Based on a 4 in. platform height.
***Engineered Aluminum 32 ft platforms can weigh approximately 250 lbs. At 600 lbs per pair total Bronco
payload capacity, that leaves 350 lbs for user, tools and materials.
SECTION
5
GENERAL SPECIFICATIONS
