Assembly drawing 35:
Before assembling the plastic gear cover, attach the included foam strips to the top of the motor and cardan shaft
platessothatthecoversitswithoutgaps.ThefourM3x3grubscrewsensurethatthefouruppersuspensionarm
screws are secure and cannot get loose.
Clip the two plastic clips (G) onto the retaining screw in front of the upper suspension arm. Attaching the
clips at the back reduces the castor angle and thus compromises the directional stability.
Assembly drawing 36:
Drawing 36 shows the assembly of tyres.
Assembly drawing 37:
The installation sites of the speed controller and the rechargeable battery are shown in drawing 37. Attach the speed
controllerinfrontofthemotorwithdoublesidedadhesivetape.FixtherechargeablebatteryusingtheVelcrostraps
included. In addition, use the thin foam pads as an underlay for the rechargeable battery. The large foam blocks must
be glued in the rechargeable battery tray so that the rechargeable battery cannot move when the model vehicle is
moving.
Thereceiverisinstalledinthereceiverboxandprotectedagainstvibrationswithfoam.Thecablesareroutedoutof
thereceiverboxonthefoam-protectededge.
Place the four foam pads on the chassis mounts and replace the chassis. Now you can adjust the chassis mounts to
the desired height and secure them with the grub screws.
The chassis can be attached to the vehicle with four chassis clips.
An overview of all vehicle parts is shown again on the last page of the assembly instructions.
