Reer EOS4 Installation, Use And Maintenance

EOS4 SAFETY LIGHT CURTAIN
16 8540733 • 23/03/2016 • Rev.17
English
Emitter connections
EOS4A - EOS4X (with integrated control functions) - EOS4XM (MASTER models)
M12 5-pin primary connectors.
1
Brown
INPUT
24VDC power supply
2
White
Light curtain configuration
complying with the EN61131-2 standard
(ref. Table 5)
3
Blue
0VDC power supply
4
Black
Light curtain configuration
complying with the EN61131-2 standard
(ref. Table 5)
5
Grey
Ground connection
Table 4 - M12, 5 pin
Master/Standard/with integrated control functions TX
24V
0V
Selection Range
0V
24V
Selection Range
0V
0V
Emitter in
24V
24V
Selection error
Table 5 – Range and TEST selection

For correct operation of the light curtain, pins 2 and 4 of the Emitter must be
connected as indicated in Table 5.
EOS4XS - EOS4XS2 (SLAVE/SLAVE2 models) - M12, 5-pin primary connector.
1
Brown
24VDC power supply
2
White
Communication
MASTER-SLAVE
3
Blue
0VDC power supply
4
Black
Communication
MASTER-SLAVE
5
Grey
Ground connection
Table 6 - M12, 5-pin Primary Slave TX
EOS4XM (MASTER models) – M12, 5-pin secondary connector.
EOS4XS2 (SLAVE2 models) – M12, 5-pin secondary connector.
1
Brown
24VDC power supply
2
White
Communication
MASTER-SLAVE
3
Blue
0VDC power supply
4
Black
Communication
MASTER-SLAVE
5
Grey
Ground connection
Table 7 - M12, 5-pin Secondary TX

Reer EOS4 Specifications

General

Power Supply	24 VDC ±20%
Resolution	14 mm
Safety Category	Type 4
Operating Temperature	+55 °C
Protection Rating	IP65
Detection Capability	Opaque objects
Connection	M12 connector
Response Time	≤ 20 ms
Outputs	2 x safety outputs (OSSDs)
