Dimensions
Figure 27 - Emitter and Receiver
213
313
363
513
663
813
963
1113
1263
1413
1563
1713
1863
236
-
386
536
686
836
986
1136
1286
1436
1586
1736
1886
150
250
300
450
600
750
900
1050
1200
1350
1500
1650
1800
2 LE TYPE brackets with 2 inserts
3 LE TYPE brackets with 3 inserts
653
953
1053
677
977
1077
590
890
990
2 LE TYPE brackets with 2 inserts
Figure 28 - FIE inserts and LE fastening brackets (provided)

Reer EOS4 Specifications

General

Power Supply	24 VDC ±20%
Resolution	14 mm
Safety Category	Type 4
Operating Temperature	+55 °C
Protection Rating	IP65
Detection Capability	Opaque objects
Connection	M12 connector
Response Time	≤ 20 ms
Outputs	2 x safety outputs (OSSDs)
