Reer EOS4 Installation, Use And Maintenance

EOS4 SAFETY LIGHT CURTAIN
2 8540733 • 23/03/2016 • Rev.17
English
Functional earth (earth connection)
Master/Slave System
Output Signal Switching Device = Light curtain’s solid state safety outputs
= Safety light curtain emitter.
= Safety light curtain receiver.
Hand protection light curtains
Arm and leg protection light curtains.
Full body protection light grids.
 This symbol indicates an important warning for Failure to comply
with this warning may result in high level risk for exposed personnel.

This symbol indicates an important warning.

Reer EOS4 Specifications

General

Power Supply	24 VDC ±20%
Resolution	14 mm
Safety Category	Type 4
Operating Temperature	+55 °C
Protection Rating	IP65
Detection Capability	Opaque objects
Connection	M12 connector
Response Time	≤ 20 ms
Outputs	2 x safety outputs (OSSDs)
