Reflex Fillcontrol Plus User Manual

Technical data
Fillcontrol Plus — 06.07.2016 - Rev. B English —
13
5 Technical data
Note!
The following values apply for all systems:
–
Permissible ambient temperature:
–
Degree of protection:
–
Noise level:
>0 °C – 45 °C
IP 54
55 dB
5.1 Electrical system
Type
Power output
(W)
Power supply
(V / Hz)
Fusing
(A)
Number of RS-485
interfaces
I/O module
Fillcontrol Plus 350 230 / 50 4 2 Optional
5.2 Dimensions and connections
Type
Weight
(kg)
Height
(mm)
Width
(mm)
Depth
(mm)
Device
connection
System
connection
Overflow
connection
Fillcontrol Plus 1.7 340 320 190 G ¾ G ½ –
Fillcontrol Plus stainless steel 2.5 340 320 190 G ¾ G ½ –
5.3 Operation
Type
Make-up capacity
(l/h)
Maximum feed
pressure
(bar)
Maximum delivery
pressure
(bar)
Permissible operating
gauge pressure
(bar)
Operating
temperature
(°C)
Fillcontrol Plus
≤
1400
10
≤
8.5
10 60
