Reflex Fillcontrol Plus User Manual

Controller
Fillcontrol Plus — 06.07.2016 - Rev. B English —
35
9.3 Messages
Messages with ER codes are displayed at the controller.
• Use the arrow keys at the controller operating panel to select the messages.
• By selecting the "Fault memory" main menu in the Customer menu, you display the last 20 alarms.
• Alarm causes can be eliminated by the operator or a specialist workshop.
• If required, please contact the Reflex Customer Service.
Note!
Confirm the elimination of the fault by pressing "Quit" at the controller operator panel. All other alarms are automatically
reset as soon as the cause has been eliminated.
Note!
Group messages are issued via a floating contact which is set in the
Customer menu, see chapter 7.4 "Parametrising the
controller in the Customer menu
" on page 25 .
ER Code
Alarm
Group
message
Causes
Remedy
Alarm reset
01 Min. pressure YES
The set value for the "P
0
"
minimum working pressure
has been exceeded.
• Water loss in the
system.
• Expansion tank
defective.
• Check the system for leaks.
• Replace the expansion tank.
• Check the function in manual
mode.
"Quit"
06 Makeup time
Set time for the makeup
time has been exceeded.
• Severe water loss in
the system.
• Makeup line not
connected.
• Makeup rate
insufficient.
• Makeup hysteresis too
high.
• Check the system for leaks.
• Connect the makeup system.
• Check the makeup rate.
• Check the makeup hysteresis.
"Quit"
07 Makeup cycles
Set value for the makeup
cycles has been exceeded.
• Leakage in the system.
• Check the system for leaks. "Quit"
08 Pressure measurement YES
Controller receives
incorrect signal.
• Pressure transducer
plug not plugged in.
• Broken wire from "PIS"
pressure transducer.
• "PIS" pressure
transducer defective.
• Plug in the plug.
• Replace the wire.
• Replace the "PIS" pressure
transducer.
"Quit"
10 Maximum pressure
Set value for the maximum
pressure has been
exceeded.
• Safety valve defective.
• Insufficient
dimensioning of the
pipeline to the system.
• Check the actuating pressure
of the safety valve.
• Replace the safety valve.
• Increase the diameter of the
pipeline to the system.
"Quit"
