Reflex Fillcontrol Plus User Manual

Controller
30
— English Fillcontrol Plus — 06.07.2016 - Rev. B
9.2 Configuring settings in the controller
Use the Customer menu to display or correct system-specific values. In the course of commissioning, the factory settings must be
adjusted for the system-specific conditions.
Note!
For a description of the operation,
see chapter 9.1 "Operator panel" on page 29 .
All grey marked menu items must be reviewed during commissioning.
• Press "Manual" to switch to manual operation.
• Press "Menu" to display the first main menu option "Customer menu".
Switch to the next mai
n menu option.
•
Press "Quit" to return to the previous main menu option.
•
Use the "▼" and "▲“ buttons to navigate within the selected main menu option.
▼
Customer menu
Set the required language.
Language
Change the flashing
display items for "Hour", "Minute" and "Seconds".
The set time is used for entries in the fault memory.
Time:
Change the flashing display items for "Day", "Month" and "Year".
This date is used for entries in the fault memory.
Date:
Magcontrol
–
Select this setting for the fresh water make-up in systems with a diaphragm expansion
tank.
Levelcontrol
–
Select this setting for the fresh water make-up in systems with a pressure maintaining
station.
Fillcontrol xx
Magcontrol
The controller displays "Min. op. pressure“ if the "Magcontrol“ make
-up variant is set.
–
Enter the "P
0
“ minimum working pressure.
–
For setting the minimum operating pressure, see chapter 7.2 "Determining the P
0
minimum operating pressure for the controller" on page 24 .
Min. op. pressure
01.8 bar (005)
The controller displays "Safety valve pressure“ if the
"Magcontrol“ make-up variant is set.
–
Enter the activating pressure of the safety valve of the heat or cooling generator.
Safety valve pressure
03.0 bar (006)
